Identify Your Steel Deck Using Our Plastic Deck Identifier

D-MAC Plastic Deck Identifier Tool

Fill out the form to register for a D-MAC Deck Identifier Tool.

Quantities are limited so only (1) Deck identifier tool per email registration.  Additional deck identifiers are $25.

D-MAC Plastic Deck Identifier Tool

Name*
Address*
MM slash DD slash YYYY

Identify Your Existing Deck Visually

 Identify These Dimensions on Your Deck…

Match these dimensions on your steel deck

With the Dimensions in this Table:

TypeHPXYZ
B-Deck1 1/2 "6 " 1 9/16 "2 1/2 "3 1/2 "
F-Deck1 1/2 "6 " 1/2 "1 3/4 "4 1/4 "
A-Deck1 1/2 "6 " 3/8 "1 "5 "
N-Deck3 "8 " 1 1/2 "2 3/4 "5 1/4 "

To determine what type of deck you need:

  1. Measure the dimensions of your current deck
  2. Match up the H,P,X,Y, and Z dimensions in the Deck Identifier image above to your deck
  3. Determine what type of deck you have: B, F, A, or N
  4. Call us and place an order

Or if you would like to visibly identify your deck:

Take a look at the images of deck below and call us for a quote:  (800) 878-3622

Steel Roof Decks

*Click on any image to enlarge

Type A Metal Roof Deck (Narrow Rib)
Type A Roof Deck
Type B Metal Roof Deck (Wide Rib)
Type B Roof Deck
Type F Metal Roof Deck (Intermediate Rib)
Type F Roof Deck
Type N Metal Roof Deck (Deep Rib)
Type N Roof Deck

Non-Composite Floor/Form Decks

9/16″ Form Deck
9/16" Form Deck
15/16″ Form Deck
15/16" Form Deck
1  5/16″ Form Deck
1 5/16" Form Deck
1  1/2″ Form Deck
1 1/2" Form Deck

Composite Floor Decks

1  1/2″ Composite Floor deck
1 1/2" Composite Floor Deck
2″ Composite Floor deck
2" Composite Floor Deck
3″ Composite Floor deck
3" Composite Floor Deck
